Norden 24 port LC Fiber Optic Patch Panel

FEATURES

Cable clamps on the inner surface for fixing cables.
19” rack mount.
Fixed type Splice tray to access pigtails available, which is designed with plexi
glass top cover & PC material.
Welded screw in the middle of inner surface for splice tray or cassette It is
designed for fibre optic termination.
ST, SC, LC, FC, MTRJ, E2000 connector plates are available.
Lockable front door on front with spring type screws.
The body is made of cold rolled steel sheet, with electrostatic spraying.



COMPLIANCE

TSE: EN 61587-1 Mechanical Structures For Electronic
Equipment – Tests for IEC 60917 and IEC 60297
Climatic and Environment: EN 61587-1/4.2, IEC60068-2-1,
IEC60068-2-2, IEC60068-2-30,
Earth Bond: EN61587-1/6.2
Flammability: EN61587-1/6.3



DESIGN & MATERIALS

Mounting Type Rack
Colour Black or Beige or white
Material Cold rolled carbon sheet steel with electrostatic spraying
Rack Type Fixed
‘U’ Size 1U=12/24 port, 2U=36/48 port, 3U=60/72 port
Cable Port Max. 2-4
Environment Temperature- Relative -40°C to +80°C
Humidity ≤ 85 % (30 degree)
Atmosphere Pressure 70-106 KPa
Insulation Resistance ≥ 20M Ohm/500V (DC)
Intensity ≤ 15kv(DC) /1min.no spark-over and no flying arc
Fibre Bending Radius ≥ 40 mm

SKU: Norden 24 port LC Fiber Optic Patch Panel Category:

Product Description

Norden 24 port LC Fiber Optic Patch Panel

FEATURES

Cable clamps on the inner surface for fixing cables.
19” rack mount.
Fixed type Splice tray to access pigtails available, which is designed with plexi
glass top cover & PC material.
Welded screw in the middle of inner surface for splice tray or cassette It is
designed for fibre optic termination.
ST, SC, LC, FC, MTRJ, E2000 connector plates are available.
Lockable front door on front with spring type screws.
The body is made of cold rolled steel sheet, with electrostatic spraying.



COMPLIANCE

TSE: EN 61587-1 Mechanical Structures For Electronic
Equipment – Tests for IEC 60917 and IEC 60297
Climatic and Environment: EN 61587-1/4.2, IEC60068-2-1,
IEC60068-2-2, IEC60068-2-30,
Earth Bond: EN61587-1/6.2
Flammability: EN61587-1/6.3



DESIGN & MATERIALS

Mounting Type Rack
Colour Black or Beige or white
Material Cold rolled carbon sheet steel with electrostatic spraying
Rack Type Fixed
‘U’ Size 1U=12/24 port, 2U=36/48 port, 3U=60/72 port
Cable Port Max. 2-4
Environment Temperature- Relative -40°C to +80°C
Humidity ≤ 85 % (30 degree)
Atmosphere Pressure 70-106 KPa
Insulation Resistance ≥ 20M Ohm/500V (DC)
Intensity ≤ 15kv(DC) /1min.no spark-over and no flying arc
Fibre Bending Radius ≥ 40 mm
