Hikvision 305 m CAT6 UTP Network Cable (CCA,0.565 mm) DS-1LN6U-W/CCA Price in Qatar

Hikvision 305 m CAT6 UTP Network Cable (CCA,0.565 mm) DS-1LN6U-W/CCA Price in Qatar

  • 305 m cost-effective CAT6 CCA network cable
  • Full diameter and full length
  • Quality verified by Fluke test
  • Guaranteed long PoE transmission distance
SKU: DS-1LN6U-W/CCA Category:

Product Description

General

  • Core Color  1 Blue & White/ Blue 2 Orange & White/ Orange,3 Green & White/ Green 4 Brown & White/ Brown,
  • Packing Carton
  • Carton Dimension   41x41x24cm
  • Packing Length        (305±1.5)m
  • Rip-Cord      Yes
  • Drain Wire   No
  • Sheath Physical Properties  Before Aging Tensile Strength (Mpa) ≥13.5, Elongation(%) ≥150,Aging Period(℃×hrs) 100℃×24h×7d,After Aging ,Tensile Strength(Mpa) ≥12.5, variance ratio:±25%, Elongation(%) ≥125, variance ratio:±20%,Cold bend(-20±2℃×4h) 8×Cable O.D.,No visible cracks,
  • Electrical Characteristics (20℃)1.0-100.0MHz Impedance(Ω) 100±15,100 – 250MHz Impedance(Ω) 100±25,1.0-100.0MHz Delay Shew (ns/100m) ≤45,DC ResistanceΩ/100m) max 12,DC Conductor Resistance Unbalance(%) max 2,

Conductor

  • Material    CCA (Copper content:27%)
  • Nom.O.D.(Mm)     0.585±0.01

Insulation

  • Material       Solid HDPE
  • Diameter     1.05±0.05mm

Sheath

  • Thickness    0.50±0.05 mm
  • External      O.D.6.0±0.30 mm
  • Surface        Clean, Frap, Satiation
  • Material      FR-PVC(complies RoHS)
  • Color           White RAL9003

Surface Printing

  • Letter Height   2.5±0.2mm
  • Color     Black
  • Print Error & Space    ≤±0.5%,1m
