Yealink W90DM Cordless IP Multi-Cell DECT Manager Price in Qatar

Product Description

Yealink W90DM – Technical Specifications

Phone Features

• Sync over the DECT and LAN (Seamless handover and roaming)
• Each Multicell System:
  – Up to 60 base stations
  – Up to 250 handsets
  – Up to 250 VoIP accounts
  – Up to 250 simultaneous calls
  – Up to 8 WB (4 active handsets) calls per base
  – Up to 8 NB calls per base
• Up to 2 simultaneous calls per handset
• Call hold, call transfer, 3-way conference
• Switching between calls
• Call waiting, mute, silence, DND
• Caller ID with name and number
• Anonymous call, Anonymous call rejection
• Call forward (always/busy/no answer)
• Speed dial, voicemail, redial
• Message Waiting Indication (MWI)
• Music on hold (server-based)
• Local phonebook for up to 100 entries per handset
• Remote phonebook/LDAP/XML phonebook
• Phonebook search/import/export
• Call history (all/missed/placed/received)
• Reset to factory, reboot
• Keypad lock, emergency call
• Broadsoft directory, BroadSoft call log
• Broadworks feature key synchronisation
• Shared Call Appearance (SCA)
• XML browser
• IPUI registration
• User access level

Management

• Auto-provision via TFTP/FTP/HTTP/HTTPS/RPS
• Auto-provision with PnP
• Handset upgrade: OTA (Over-The-Air)
• Configuration: browser/phone/auto-provision
• Trace package and system log export

Audio Features

• Full-duplex speakerphone
• Hearing Aid Compatibility (HAC) compliant
• DTMF
• Wideband codec: Opus, AMR-WB (optional), G.722
• Narrowband codec: AMR-NB (optional), PCMU,PCMA, G.726, G.729, iLBC
• VAD, CNG, AGC, PLC, AJB

Network Features

• SIP v1 (RFC2543), v2 (RFC3261)
• SNTP/NTP
• VLAN (802.1Q and 802.1P)
• 802.1x, LLDP
• STUN Client (NAT Traversal)
• UDP/TCP/TLS
• IP assignment: static/DHCP
• Support outbound proxy server backup

Security

• Open VPN
• Transport Layer Security (TLS1.0/TLS1.1/ TLS1.2)
• HTTPS (server/client), SRTP
• Digest authentication
• Secure configuration file via AES encryption
• Support SHA256/SHA512/SHA384

DECT

• Frequency bands: 1880 – 1900 MHz (Europe), 1920 – 1930 MHz (US)
• DECT Standards: CAT-iq2.0

Interface

• 1 x RJ45 10/100M Ethernet port
• Power over Ethernet (IEEE 802.3af), Class 1

Physical Features

• Indoor Range: 30m~50m (The ideal distance is 50m)
• Outdoor Range: 300m (in ideal conditions)
• Wall mountable
• Three LED indicators on W90DM/W90B:
  – 1 x LAN (Power Indicator & Network Status) LED
  – 1 x Role LED
  – 1 x DECT LED
• External Yealink AC adapter: AC 100-240V Input and DC 5V/1.2A Output
• Colour: Pearl White
• Dimension: 134mm x 100mm x 28mm
• Operating humidity: 10~95%
• Operating temperature: 0~+40°C (+32~104°F)

Package Features

• Package content:
  – W90DM/W90B
  – Expansion Screws
  – Quick Start Guide
  – Power Adapter (optional)
• Qty/CNT: 10 PCS
• Giftbox size: 158 mm x 203 mm x 63 mm
• Carton meas: 420 mm x 338 mm x 167 mm
• N.W: 2.8kg
• G.W: 3.4kg
