Planet IPOE-E302 PoE Injector/Splitter/Extender – Price in Qatar

Industrial IP67 1-Port 802.3bt PoE++ to 2-Port 802.3at/bt PoE++ Extender.

Today’s IP surveillance technology makes the remote extension of IP cameras easy and the management of monitoring more effective. With the IPOE-E302, users do not have to change their existing network systems. The extender is an ideal solution for the expansion and extension of the current network infrastructures without having to add any cables and other related components and parts.

SKU: IPOE-E302 Category: Planet Switches

Product Description

Hardware Specifications
Network Connector	PoE in Port 1 x 10/100/1000BASE-T Ethernet with 802.3bt PoE++ “Data + DC” in Auto MDI/MDI-X, auto-negotiation RJ45 connector PoE out Port 2 x 10/100/1000BASE-T Ethernet with IEEE 802.3at/bt PoE++ “Data + DC” out Auto MDI/MDI-X, auto-negotiation RJ45 connector
LED Display	LNK/ACT LED x 3
Dimensions (W x D x H)	150 x 43.8 x 72.94 mm (W x D x H) 169.85 x 43.8 x 72.94 mm (W x D x H), with cable gland
Weight	339g 372g(with three waterproof cable glands)
Power Consumption	95.6 watts / 326.2BTU (Full loading with PoE function)
ESD Protection	Air 8KV DC Contact 6KV DC
Surge Protection	6KV
Enclosure	IP67-rated and IK10 aluminum case
Installation	Wall-mount ear
Switching Specifications
Switch Architecture	Store-and-Forward switch architecture
MAC Address Table	2K MAC address table with auto learning function
Data Buffer	1Mbit
Switch Fabric	6Gbps
Switch Throughput	4.46Mpps @ 64Bytes
Flow Control	IEEE 802.3x pause frame for full duplex Back pressure for half duplex
Jumbo Frame	9Kbytes
Power over Ethernet
PoE Standard	PoE in Port IEEE 802.3bt PoE++ Type 4 standard PD IEEE 802.3bt PoE++ Type 3 standard PD IEEE 802.3at PoE+ end-span/mid-span PD Per PoE out Port IEEE 802.3bt PoE++ end-span/mid-span PSE
PoE Power	PoE in Port 52~57V DC, max. 95 watts Per PoE out Port 50~55V DC, max. 60 watts
Power Pin Assignment	PoE in Port 1/2 (-), 3/6 (+), 4/5 (+), 7/8 (-) or 1/2 (+), 3/6 (-), 4/5 (+), 7/8 (-) Per PoE out Port 1/2 (-), 3/6 (+), 4/5 (+), 7/8 (-)
PoE Power Budget	60 watts (max.) @ 802.3bt PoE++ Type 3 input 30 watts (max.) @ IEEE 802.3at PoE+ input IEEE 802.3af PoE input not supported
Standards Conformance
Regulatory Compliance	FCC Part 15 Class A CE
Stability Testing	IEC 60068-2-32 (Free fall) IEC 60068-2-27 (Shock) IEC 60068-2-6 (Vibration)
Standards Compliance	IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3ab Gigabit Ethernet IEEE 802.3x Flow Control IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus IEEE 802.3bt Power over Ethernet Plus Plus
Environment
Operating	Temperature: -40 ~ 75 degrees C Relative Humidity: 5 ~ 95% (non-condensing)
Storage	Temperature: -40 ~ 85 degrees C Relative Humidity: 5 ~ 95% (non-condensing)
