Planet ELA-100 Fast Ethernet Switch – Price in Qatar

Ethernet Lightning Arrest Box.

When installing the ELA-100 in an outdoor place with shelter, the Ethernet Lightning Arrest Box must be earthed or else the Ethernet Lightning Arrest Box may get electric shock and damage. Then connect two Ethernet devices to the two passive 10/100/1000Base-T ports (protected port and un-protected port) of Ethernet Lightning Arrest Box for lightning strike prevention.

SKU: ELA-100 Category: Planet Switches

Product Description

Ethernet interface	2 passive 10/100/1000 Ethernet ports
Ground	1 ground position
DC spark-over voltage	230V, ±20%
Nominal impulse discharge current (wave 8 / 20μs)	20KA
Arc Voltage at 1A	~35V
Glow to arc transition current	~1A
Glow voltage	~200V
Dimensions (W x D x H)	65 x 42 x 20mm
Weight	80g
Operating environment	0~50 degrees C, 5%~90%RH
Storage environment	-20~70 degrees C, 5%~90%RH
