DS-K2210

Hikvision Elevator Master Controller DS-K2210 Price in Qatar

Master elevator controller
Control 128 floors’ permissions
20,000 cards and 50,000 events storage
Uplink Communication: TCP/IP and RS-485
Multiple authentication modes
Configure and manage device via web client and client software
Watchdog and tamper-proof function
Accessible Card Reader: 2 Wiegand readers or 2 RS485 readers

SKU: DS-K2210 Category: Hikvision Access Control

Description
Reviews (0)

Device Interface

Communication TCP/IP;RS-485, and Wiegand
Input Interface 1 Panic Button; 1 Fire Alarm Button; 1 Maintenance Button
Output Interface 5 Relay Outputs
Internal Clock Support
RTC Support

General

Working Temperature -40°F to 158°F
Working Humidity 0% to 90% (No Condensation)
Power Supply 12 VDC±15%
Installation Guide Rail Installation
Dimensions 167(L)mm*105(W)mm*30(H)mm

System Parameter

Processor 32 bit
Indicator Power On: Solid Green, Running Properly: Flashing Green, Running Exception: Solid Red, Serial Port Not Communicating: Off, Serial Port Communicating: Solid Green,Relay NC: Off, Relay NO: Solid Green, Network Disconnected: Off, Network Cable Connected: Solid Yellow, Flashing Green,Network Armed: Solid Yellow, Flashing Green,
Card Reader Up to 2 RS-485 Card Readers or 2 Wiegand Card Readers
