Gigabyte B550M AORUS ELITE AM4, Max. 128 GB DDR4, PCIe 4.0, Micro-ATX, AMD B550 Chipset, AM4 Socket, 4 x Dual-Channel DDR4-4733 (OC), Motherboard Price in Qatar

CPU Socket: AM4
Interface: PCIe 4.0
Maximum Capacity: 128 GB
Chipset: AMD B550

SKU: B550M AORUS ELITE Category: Gigabyte Motherboard

Product Description

The Gigabyte BB550M AORUS ELITE AM4 Micro-ATX Motherboard is designed around the AMD B550 chipset, supporting 3rd Gen AMD Ryzen processors with an AM4 socket. It has four memory slots, supporting up to 128GB of dual-channel RAM, which can run at up to 4733 MHz (O.C.). This motherboard features a micro-ATX form factor, which fits in smaller cases. Other integrated features include Realtek Gigabit Ethernet, Realtek 7.1-channel audio support, RGB Fusion 2.0 support, and Gigabyte Q-Flash Plus.

PCIe 4.0 Bandwidth

This motherboard pairs third-generation AMD Ryzen processors with high PCIe 4.0 memory bandwidth through the B550 chipset for maximum performance.

Dual NVMe PCIe 4.0/3.0 M.2 Connectors

With NVMe PCIe 4.0/3.0 x4 and PCIe 3.0 x4 M.2 connectors, this motherboard allows you to experience NVMe mode or SATA mode connectivity. Delivering up to 64 Gb/s data transfer speed, the dual M.2 connectors support RAID 0/1/10 modes.

Realtek LAN

Realtek LAN provides high performance for gamers and features automatic bandwidth allocation to ensure highest network priority.

HDMI 2.1

HDMI 2.1 offers 48 Gb/s of bandwidth, which unlocks the ability to transfer multiple video streams as well as a native cinematic 21:9 aspect ratio, and Full HDR and HDCP 2.3 support. HDMI 2.1 is also backward compatible with HDMI 2.0/1.4.

Smart Fan 5

Smart Fan 5 keeps your system cool, allowing you to interchange the fan headers to reflect different thermal sensors at different locations on the motherboard. Smart Fan 5 supports both PWM and Voltage mode fans, making this motherboard more liquid-cooling friendly.

RGB Fusion 2.0

RGB Fusion 2.0 gives you full control of onboard RGB and external RGB devices and lights. Already feature filled with customizable colors and patterns, RGB Fusion 2.0 also has addressable LED support.

Q-Flash Plus

Update the BIOS easily without installing the CPU, memory, and graphics card with Gigabyte Q-FLASH PLUS. You don’t have to install components or enter the BIOS menu to flash the BIOS. Just download and save a new BIOS file on the USB flash drive, then press the dedicated Q-FLASH PLUS button.

Other Specs

Internal I/O
Expansion Slots 1 x PCIe 4.0 x16
1 x PCIe 3.0 x16 (x4 mode)
1 x PCIe 3.0 x1
Air Cooling 1 x 4-Pin CPU
2 x 4-Pin System
Power Connectors 1 x 24-Pin Mainboard
1 x 8-Pin ATX
Security TPM Module
LED Header 5 x RGB
Diagnostics Clear CMOS, Flash BIOS
Legacy 1 x Serial
BIOS
ROM 256 Mb
Audio
Audio Codec Realtek ALC887 (7.1-Channel)
Software
Supported Operating Systems Windows 10 (64-Bit)
Physical
Form Factor Micro-ATX
Dimensions 9.6 x 9.6″ / 24.4 x 24.4 cm

Details

General
Chipset AMD B550
CPU Socket AM4
Back Panel I/O
USB 4 x USB 3.1 / USB 3.2 Gen 1 Type-A
4 x USB 2.0 Type-A
Display 1 x HDMI
1 x DVI-D
Audio 3 x 3.5 mm
Ethernet / Controller 1 x Realtek Gigabit
PS/2 1 x Combo
Memory
Memory Slots 4 x 288-Pin
Memory Support DDR4 2133, 2400, 2667, 2933, 3200, 3333, 3600, 4000, 4400, 4600, 4733 MHz
Maximum Capacity 128 GB
Channel Architecture Dual Channel
ECC Support Non-ECC Unbuffered
Storage Expansion
SATA 4 x SATA III
M.2 1 x M Key 2242, 2260, 2280, 22110 (PCIe 4.0 x4, PCIe 4.0 x2, PCIe 3.0 x2, PCIe 3.0 x4, SATA (Unspecified))
1 x M Key 2242, 2260, 2280 (PCIe 3.0 x2, SATA (Unspecified))
RAID Support RAID 0, 1, 10

CPU Socket

Interface

PCIe 4.0

Maximum Capacity

128 GB

Chipset

AMD B550
