Dahua VTO4202F-X Series Modular Outdoor Station Price in Qatar

Add to cart
View details

Dahua VTO4202F-X Series Modular Outdoor Station Price in Qatar

> Modules make the device with great expansibility

> Anodized front aluminum panel; IK07

> Supports voice and video communication

> 2 MP high definition fisheye camera with 160° view range

> Access control function; controls two locks

> Compatible with 2-wire interface and RJ45 interface

> Surface mount and flush mount

> IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)

SKU: VTO4202F-X Series Category:

Product Description

Technical Specification
Model DHI-VTO4202F-P
System
Main Processor SoC processor
Operating System Embedded Linux operation system
Network Protocol IPv4, RTSP, RTP, TCP, UDP, SIP, P2P
Basic
Camera CMOS Low illumination 2MP HD colorful 160° fisheye camera
Angle of View H:160°, V:82°, D:180°
Focal Length 1.95 mm
WDR WDR
Noise Reduction Noise suppression and echo cancellation
Video Encoding H.264
Frame Rate PAL: 25 fps; NTSC: 30 fps
Video Bit Rate 256K to 2M
Light Compensation IR light
Day/Night Switch Yes
Audio Encoding PCM G.711 A G.711 U
Audio Input Built-in omnidirectional microphone
Audio Output Built-in loudspeaker
Audio Bit Rate 16 Khz 16bit
Function
Communication Methods Digital communication
Unlock Mode Remote unlocking
Auto Snapshot Yes
Leave Videos or Text Messages Yes
Web Configuration Yes
Performance
Housing Material Aluminum
Port
RS-485 Port 1 RS-485 half-duplex port
Alarm Output Port 1
Power Output Port 1-ch DC 12V output 100mA
Unlock Button Exit button for opening the door
Door Status Detection Detects door magnetic status
Door Lock Control NC/COM/NO
Ethernet Port 10/100 Mbps self-adaptive Ethernet/2-wire
Alarm
Tamper Alarm Tamper alarm
Regular
Ingress Protection IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
Appearance Color Silver
Housing Material Aluminum
Power Supply Mode DC 12V/2-Wire IP Inteface/PoE
Installation Method Surface mount and flush mount
Accessory Mounting box
Dimensions 100 mm × 100 mm × 49.30 mm (3.94″ × 3.94″ × 1.94″)
Protection Grade IK07, IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide)
Working Temperature –20 °C to +60 °C (–4 °F to +140 °F )
Working Humidity 10%–90% (RH)
Power Consumption ≤ 12 W
Net Weight 0.35 kg (0.77 lb)
Gross Weight 0.4 kg (0.88 lb)
Model DHI-VTO4202F-MK DHI-VTO4202F-ML
System
Main Processor Embedded MCU processor
Button
Button Type Metal backlight keyboard (0–9, *, #) –
Indicator
Indicator Lights – 3
Port
Power Output Port DC 5V (Provide power for other modules)
Regular
Power Supply Mode DC 5V (Provided with power by other modules)
Color Silver
Dimensions 100 mm × 100 mm ×

31 mm

(3.94” × 3.94” × 1.22”)

 100mm × 49.90 mm ×

28.50 mm

(3.94” × 1.96” × 1.12”)
Protection Grade IK07; IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
Operating Temperature –20 °C to +60 °C (–4 °F to +140 °F )
Operating Humidity 10%–90% (RH)
Power Consumption 1 W
Gross Weight 0.32 kg (0.71 lb) 0.19 kg (0.42 lb)
Model DHI-VTO4202F-MR DHI-VTO4202F-MS
System
Main Processor Embedded MCU processor
Capacity
Card 10000 –
Display
Display – 3.0 inch STN display
Port
Power Output Port DC 5V (Provide power for other modules)
Regular
Power Supply Mode DC 5V (Provided with power by other modules)
Color Silver
Dimensions 100 mm × 49.90 mm × 28.50 mm

(3.94” × 1.96” × 1.12”)

 100 mm × 100 mm × 28.50 mm

(3.94” × 3.94” × 1.12”)
Protection Grade IK07; IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
Operating Temperature –20 °C to + 60 °C (–4 °F to + 140 °F )
Operating Humidity 10%–90% (RH)
Power Consumption 1 W
Gross Weight 0.17 kg (0.37 lb)
Model DHI-VTO4202F-MN
Regular
Appearance color Silver
Dimensions 100 mm × 49.90 mm × 28.50 mm (3.94” × 1.96” × 1.12”)
Protection grade IK07; IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
Gross Weight 0.16 kg (0.32 lb) 0.34 kg (0.75 lb)
Model DHI-VTO4202F-MB1

DHI-VTO4202F-MB2

 DHI-VTO4202F-MB5 DHI-VTO4202F-MF
System
Main Processor Embedded MCU processor
Capacity
Fingerprint – 3000
Button
Button Type Mechanical button –
Port
Power Output Port DC 5V (Provide power for other modules)
Regular
Power Supply Mode DC 5V (Provided with power by other modules)
Color Silver
Dimensions 100 mm × 49.90 mm × 30.50 mm (3.94” × 1.96” × 1.20”) 100 mm × 100 mm × 31 mm

(3.94” × 3.94” × 1.22”)

 100 mm × 100 mm × 38.50 mm

(3.94” × 3.94” × 1.52”)
Protection Grade IK07; IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
Operating Temperature –20 °C to +60 °C (–4 °F to +140 °F )
Operating Humidity 10%–90% (RH)
Power Consumption 1 W
Gross Weight 0.18 kg (0.40 lb) 0.31 kg (0.68 lb) 0.33 kg (0.73 lb)
Appearance Color Silver
