Dahua TPC-ACPT8620B-B Thermal Network Anti-corrosion Hybrid PTZ Camera Price in Qatar

Thermal Camera

Image Sensor

Uncooled VOx Microbolometer

Effective Pixels

640(H)x512(V)

Pixel Size

17um

Thermal Sensitivity(NETD)

<40mK@f/1.0

Spectral Range

7~14um

Image Setting

Brightness/Sharpness/ROI/AGC/FFC/3D DNR

Color Palettes

14(Whitehot/Blackhot/Ironrow/Icefire/

Fusion/Rainbow/Globow/Iconbow1/

Iconbow2 .etc)

Thermal Lens

Lens Type

Motorized

Focus Control

Auto / Manual

Focal Length

20 ~ 100mm

30 ~ 150mm

Angle of View

H:31.6° ~ 6.2°, V:25.1° ~ 5°

H:21.0° ~ 4.1°, V:16.8° ~ 3.3°

Effective Distance①

Man(1.8m*0.5m)

D:3000m

R:750m

I :380m

D:4500m

R:1150m

I :570m

Effective Distance

Vehicle(2.3m*2.3m)

D:8800m

R:2300m

I :1200m

D:13200m

R:3500m

I :1800m

Visible Camera

Image Sensor

1/1.9″ Sony CMOS

Effective Pixels

1944(H)x1092(V)

Electronic Shutter Speed

1/1 ~ 1/30,000s

Min. Illumination

0.002Lux@F1.5(Color), 0.0005Lux@F1.5(B/W)

S/N Ratio

More than 55dB

IR Distance

NA

IR On/Off Control

NA

IR LEDs

NA

Visible Lens

Focal Length

15.6 ~ 500mm

12.5 ~ 775mm

Max Aperture

F3.9

F3.8

Angle of View

H:27.5° ~ 0.9°

H:28.8° ~ 0.5°

Optical Zoom

32X

62X

Focus Control

Auto / Manual

Close Focus Distance

100mm ~ 1000mm (0.33ft ~ 3.28ft)

PTZ

Pan/Tilt Range

Pan: 0° ~ 360° endless;Tilt: -60° ~ 45°(-60° ~ 60° optional)

Manual Control Speed

Pan: 0.01° ~12° /s; Tilt: 0.01° ~9° /s

Preset Speed

Pan: 0.01° ~12° /s ;Tilt: 0.01° ~9° /s

Preset

300

PTZ Mode

5 Auto Scan, 8 Tour, 5 Pattern, Auto Pan

Speed Setup

Human-oriented focal length/ speed adaptation

Power Up Action

Auto restore to previous PTZ and lens status

after power failure

Idle Motion

Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period

Protocol

DH-SD, Pelco-P/D (Auto recognition)

Video

Compression

H.264 / MJPEG

Frame Rate

Main Stream:

Thermal: 1280×1024(default) / 720P @1~25/30fps

Visible: 1080P(default) /720P @1~25/30fps

Sub Stream:

Thermal: 640×512(default) / 320×256 @1~25/30fps

Visible: CIF(default) / D1 @1~25/30fps

Bit Rate Control

CBR / VBR

Bit Rate

H.264: 640 ~8192Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / WDR

White Balance

Auto / ATW / Indoor / Outdoor / Manual

Noise Reduction

3D DNR

Motion Detetion

Off / On (4 zone, Rectangle)

Region of Interest

Off / On (4 zone)

Electronic Image Stabilization

(EIS)

NA

Defog

Off / On

Digital Zoom

24x

Flip

180°

Mirror

Off / On

Privacy Masking

Off / On (4 area, Rectangle)

Audio

Compression

G.711A / G.711Mu / AAC

Intelligence

IVS

Tripwire, Intrusion, Object Abandoned/Missing

Advanced Intelligent Functions

Fire detection & alarm

Tracking Trigger Mode

NA

Tracking Trigger Event

NA

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, ONVIF

Interoperability

ONVIF Profile S&G, PSIA, CGI

Streaming Method

Unicast / Multicast

Max. User Access

10 Users / 20 Users

Edge Storage

Micro SD (256GB)

Memory status display (Normal / Error / Active / Formatting / Lock),

NAS (Network Attached Storage), Local PC for instant recording

Web Viewer

Management Software

Smart PSS, DSS

Smart Phone

Android, Ios

Certifications

Certification

CE (EN 60950:2000), FCC (FCC Part 15 SubpartB ), NEMA 4X

Interface

Video Interface

1.0Vp-p/75Ω, PAL / NTSC (HDCVI Optional)

Audio Interface

Input/Output 1 Input / 1 Output

RS485

Support

Alarm

2/2 In/Out

Electrical

Power Supply

100 ~ 300V AC

Power Consumption

100W, Max. 130W (Heater on)

Environmental

Operating Condition

-35°C ~ +65°C (-31°F ~ +149°F) / (-40°C ~ +70°C optional) / Less than 95% RH

* Start up should be done at above -40°C (-40°F)

Strorage Conditions

-40°C ~ +70°C (-40°F ~ +158°F) / Less than 95% RH

Ingress Protection

IP66

Construction

Casing

Metal

Dimensions

640mm x 400mm x 612mm (25.2″x 15.7″ x 24.1″)

Net Weight

50Kg (110.2 lb)

Gross Weight

68Kg (149.9 lb)
