Commscope Cat6 Cable Price in Qatar

CS34Z3 Category 6 U/UTP Cable, low smoke zero halogen, white jacket, 4 pair count, 1000 ft (305 m) length CommPak

SKU: 884032314 Category: Commscope

Product Description

Construction Materials
Jacket Material	Low Smoke Zero Halogen (LSZH)
Conductor Material	Bare copper
Insulation Material	Polyolefin
Separator Material	Polyolefin

Dimensions
Cable Length	305 m \| 1000 ft
Cable Weight	19.10 lb/kft
Diameter Over Jacket, nominal	5.715 mm \| 0.225 in
Jacket Thickness	0.559 mm \| 0.022 in

Electrical Specifications
ANSI/TIA Category	6
Characteristic Impedance	100 ohm
dc Resistance Unbalance, maximum	5 %
dc Resistance, maximum	9.38 ohms/100 m
Delay Skew, maximum	24 ns
Mutual Capacitance at Frequency	5.6 nF/100 m @ 1 kHz
Nominal Velocity of Propagation (NVP)	69 %
Operating Frequency, maximum	250 MHz
Operating Voltage, maximum	80 V
Transmission Standards	ANSI/TIA-568-C.2 \| CENELEC EN 50288-6-1 \| ISO/IEC 11801 Class E
Safety Voltage Rating	300 V
Dielectric Strength, minimum	1500 Vac \| 2500 Vdc
Note	All electrical transmission tests include swept frequency measurements
