Cisco ASA5545-CU-2AC-K9 Firewall Price in Qatar

Cisco ASA5545-CU-2AC-K9 includes firewall services, 2500 IPsec VPN peers, 2 SSL VPN peers, 14 copper Gigabit Ethernet data ports, 1 copper Gigabit Ethernet management port, 1+1 AC power supply, Active/Active High Availability, 2 security contexts, 3DES/AES license.

SKU: ASA5545-CU-2AC-K9 Category: Cisco-Firewall

Product Description

Product Code	ASA5545-CU-2AC-K9
Interfaces	14 copper GE ports, 1 copper GE management port, 1+1 AC power supply
Stateful inspection throughput (maximum)	3 Gbps
3DES/AES VPN throughput	400 Mbps
IPsec VPN peers	2,500
Virtual interfaces (VLANs)	300
Memory	12 GB
Flash	8 GB
Height (rack units)	1 RU
Dimensions (D x H x W)	4.24 x 42.9 x 48.4 cm

Table 3 shows the comparison of ASA5545-CU-2AC-K9 and ASA5545-K9.

Models	ASA5545-CU-2AC-K9	ASA5545-K9
Description	Cisco ASA 5545-X Firewall Edition; includes firewall services, 2500 IPsec VPN peers, 2 SSL VPN peers, 14 copper Gigabit Ethernet data ports, 1 copper Gigabit Ethernet management port, 1+1 AC power supply, Active/Active High Availability, 2 security contexts, 3DES/AES license	Cisco ASA 5545-X Firewall Edition; includes firewall services, 2500 IPsec VPN peers, 2 SSL VPN peers, 8 copper Gigabit Ethernet data ports, 1 copper Gigabit Ethernet management port, 1 AC power supply, Active/Active High Availability, 2 security contexts, 3DES/AES license
Stateful Inspection Throughput (maximum)	3 Gbps	3 Gbps
Next-generation firewall throughput (multiprotocol)	1 Gbps	1 Gbps
Memory	12GB	12GB
Flash	8GB	8GB
Height (rack units)	1RU	1RU

ASA5545-CU-2AC-K9 Specification

ASA5545-CU-2AC-K9 Specification
Stateful Inspection Throughput (Maximum)	3 Gbps
Stateful Inspection Throughput (Multiprotocol)	1.5 Gbps
IPS Throughput	900 Mpbs
Next-Generation Throughput(Multiprotocol)	1 Gbps
3DES/AES VPN Throughput	400 Mbps
Users/Nodes	Unlimited
IPsec VPN Peers	2,500
Cisco Cloud Web Security Users	5,000
Premium AnyConnect VPN Peers(Included/Maximum)	2/2500
Concurrent Connections	750,000
New Connections/Second	30,000
Virtual Interfaces (VLANs)	300
Security Contexts (Included/Maximum)	2; 50
High Availability	Active/Active and Active/Standby
Expansion Slot	1 interface card
User-Accessible Flash Slot	–
USB 2.0 Ports	2
Integrated I/O	14 GE Copper
Expansion I/O	6 GE Copper or 6 GE SFP
Serial Ports	1 RJ-45 console
Solid State Drive	2 slot, RAID 1 120 GB MLC SED
Memory	12 GB
Minimum System Flash	8 GB
System Bus	Multibus architecture
Temperature	23 to 104°F (-5 to 40°C)
Relative Humidity	90 percent noncondensing
Altitude	Designed and tested for 0 to 10,000 ft (3050m)
Shock	50G, 2 m/sec
Vibration	0.41 Grms2 (3 to 500 Hz) random input
Acoustic Noise	64.2 dBa max
Temperature	-13 to 158ºF (-25 to 70ºC)
Relative Humidity	10 to 90 percent noncondensing
Altitude	Designed and tested for 0 to 15,000 ft (4572m)
Shock	70G, 4.22 m/sec
Vibration	1.12 Grms2 (3 to 500 Hz) random input
AC Range Line Voltage	100 to 240 VAC
AC Normal Line Voltage	100 to 240 VAC
AC Current	4.85A
AC Frequency	50/60 Hz
Dual-Power Supplies	Yes
DC Domestic Line Voltage	-40.5 to 56 VDC (-48 VDC nominal)
DC International Line Voltage	-55 to -72 VDC (-60 VDC nominal)
DC Current	15A (maximum input)
Steady State	86W
Maximum Peak	125W
Maximum Heat Dissipation	427 BTU/hr
Form Factor	1 RU, 19-in. rack-mountable
Dimensions (H x W x D)	1.67 x 16.7 x 19.1 in. (4.24 x 42.9 x 48.4 cm)
Weight (with AC Power Supply)	16.82 lb (7.63 kg) with single power supply 18.86 lb (8.61 kg) with dual power supply
Safety	IEC 60950-1: 2005, 2nd Edition EN 60950-1:2006+A11: 2009 UL 60950-1:2007, 2nd Edition; CSA C22.2 No. 60950-1-07, 2nd Edition
Electromagnetic Compatibility (EMC)	CE: EN55022 2006+A1: 2007 Class A; EN55024 1998+A1:2001+A2:2003; EN61000-3-2 2009; EN61000-3-3 2008; FCC: CFR 47, Part 15 Subpart B Class A 2010, ANSI C63.4 2009; ICES-003 ISSUE 4 FEBRUARY.2004; VCCI: V-3/2011.04; C-TICK: AS/NZS CISPR 22,2009 KC: KN22 & KN24
Industry Certifications	In process
