Palm-Size Doorphone

Stylish and space-saving, Akuvox E11 is a SIP video doorphone specially designed for villas, houses and apartments.

SKU: E11 Category:

Product Description

At a Glance

Wide-angle camera: 116° (H), 60° (V);
PoE (IEEE802.3af, Power-over- Ethernet);
Two-way audio communication over IP networks with Echo Cancel feature;
Complies with SIP standard for easy integration in every SIP capable PBXes;
Complies with ONVIF standard for easy integration with any network surveillance system;

Physical & Power

Front panel: Plastic
Camera.2M pixels, automatic lighting
Button: 1 call button
Light sensor: Support
Infrared sensor: Support
Wiegand port: Support
RF card reader: 13. 56MHz & 125kHz
Relays out: 2
Inputs: 2
Microphone: – 40dB
Speaker: 4Ω / 3W
Ethernet port: RJ45, 10/100Mbps adaptive
802.3af Power- over- Ethernet
12V DC connector (if not using PoE)
Installation: Wall-mounted
Wall-mounted DIM: 145x85x27.5mm
Working Humidity: 10~90%
Working Temperature: -20°C ~ +65°C
Storage’ Temperature: -40°C ~ +70°C

Audio

SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec: G.711a, G.711μ, G.729
Broadband audio codec: G.722
DTMF: In-band, out-of-band DTMF (RFC2833),
SIP Info
Echo Cancellation
Voice Activation Detection
Comfort Noise Generator

Video

Sensor: 1/2.7″, CMOS
Pixels: CIF, QCIF, VGA, 4CIF, 720p
Video codec: H.264
Video resolution: up to 1280x720p
Max. image transfer rate: 720p – 30fps
Viewing angle: 116*(H) / 60°(V)
High intensity IR LEDs for picture lighting during dark hours with internal light sensor
Compatible to 3″- Party- Video components, e.g. NVRs

Door Entry Feature

Relays controlled individually by DTMF tones
Camera permanently operational
Auto-night mode with LED illumination
White balance: auto
Minimum illumination: 0.1LUX

Networking & Protocol

Protocols support: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP

Deployment & Maintenance

Auto- Provisioning
Web management portal
Web- based packet dump
Configuration backup/ restore
Entry log export
Access table export / import
Firmware upgrade
System logs (include door access logs)

Application Scenario

Office doorphone with on-site or hosted IP- PBX
Remote site entry over Internet
Apartment/flat intercom with door access control
